BASIC OPERATIONS
When the screen is displayed, press the and choose the measurement
mode.
After choosing the eye to be measured, press the and finish setting.
In the initial setting, the mode for continuous measurement of both eyes is set.
When the measurement of the right/left eye only is selected by the , the
mode is changed to the initial setting of continuous both eye measurement after printing
out the measurement result.
If is selected when the main body is positioned for measuring the right eye, or if
is selected when the main body is positioned for measuring the left eye, the main
body moves after pressing the and the right/left is changed.
