TestProcedure

1.Parkthemachineonalevelsurfacewiththereelengageswitchoff,lowerthe

cuttingunits,shutofftheengine,mowspeedlimiterisintheMOWposition,

andsettheparkingbrake.

CAUTION

Beforeopeningthehydraulicsystem,operateallthehydraulic

controlstoreleasesystempressureandavoidinjuryfromthe

pressurizedhydraulicuid;refertoReleasingPressurefromthe

HydraulicSystem(page6–8).

2.ReadallWarning,Cautions,andprecautionslistedatthebeginningofthis

section.

g217940

Figure129

1.Reelmotorinlethose

2.#4cuttingreelmotor

3.TotestthefrontcuttingunitcircuitreliefvalveRV2,cleananddisconnectthe

inlethosetothe#4(frontleft)cuttingunitmotor(Figure129).

HydraulicSystem:TestingtheHydraulicSystem

Page6–124

Reelmaster

5410/5510/5610Series

15216SLRevC
