TestProcedure(continued)
g217937
Figure130
1.Reelmotorinlethose
2.#2cuttingreelmotor
4.TotesttherearcuttingunitcircuitreliefvalveRV1,cleananddisconnectthe
inlethosetothe#2(rearleft)cuttingunitmotor(Figure130).
IMPORTANT
Ensurethattheuidowindicatorarrowontheowmeteris
showingthattheuidwillowfromthedisconnectedhose,through
thetester,andintothereelmotor.
5.Installthetesterwithapressuregaugeandowmeterinserieswiththe
disconnectedhoseandthereelmotor.Ensurethattheowcontrolvalve
ontesterisfullyopen.
6.UsetheInfoCenterdisplaytosetreelspeedcontroltothefullspeedsetting.
Ensurethatthemow/backlapleveronthemowcontrolmanifoldisinthe
MOWposition.
7.Ensurethatthehydraulicuidisatnormaloperatingtemperatureby
operatingthemachineforatleast10minutes.
8.Withtheenginerunning,presstheenginespeedswitchtofullspeed(3,005
to3,055rpm)position.UsetheInfoCentertocheckthattheenginespeedis
correct.
WARNING
Keepawayfromthecuttingreelduringthetesttopreventpersonal
injury.
9.Haveasecondpersontooccupytheseat,pressthereelengageswitchtoON
position,andthenmovethejoystickleverforwardtoengagethecuttingunits.
Reelmaster
®
5410/5510/5610Series
Page6–125
HydraulicSystem:TestingtheHydraulicSystem
15216SLRevC
