Toro 30413 Service Manual

Groundsmaster 4100--D/4110--DHydraulic System Page 4 -- 72
Traction Linkage Adjustment
1. Traction pedal
2. Cap screw (4 used)
3. Hex nut (2 used)
4. Pedal stop
5. Washer head screw (2 used)
6. Pedal bracket
7. Lock nut (4 used)
8. Traction rod
9. Slotted roll pin
10. Lock nut
11. Flat washer
12. Compression spring
13. Spring retainer
14. Roll pin
15. Spring bracket
16. Spring shaft
17. Jam nut (3 used)
18. Cap screw (2 used)
19. Rod end (3 used)
20. Spacer
21. Traction lever
22. Lock nut
23. Spacer
24. Flange bushing
25. Cap screw
26. Grease fitting
27. Traction pump control arm
28. Hex nut
29. Flat washer
Figure 52
FRONT
RIGHT
2
3
6
8
9
10
11
13
1
5
7
12
14
15
16
17
18
19
20
4
19
19
21
22
23
24
25
26
27
28
29
10
18
17
20
24
