Toshiba TOSVERT VF-AS3 User Manual

E6582062
11. Table of parameters 11-38
1
9
11
F710 0710
Standard mode
display
0 - 162
*3
--0Y
[4. 2. 3]
[5. 4. 3]
[6. 34. 5]
F711 0711
Monitor mode 1
display
--2Y
[6. 34. 6]
[8. 1. 1]
F712 0712
Monitor mode 2
display
--3Y
F713 0713
Monitor mode 3
display
--4Y
F714 0714
Monitor mode 4
display
--8Y
F715 0715
Monitor mode 5
display
--18Y
F716 0716
Monitor mode 6
display
--19Y
F717 0717
Monitor mode 7
display
--35Y
F718 0718
Monitor mode 8
display
--34Y
F719 0719
Run command clear
select
0: Clear at coast stop.
Retain at MOFF and
when CMOd is
changed.
1: Retain run command.
2: Clear at coast stop
and at MOFF. Retain
when CMOd is
changed.
3: Clear at coast stop, at
MOFF and when
CMOd is changed.
- - 2 Y [6. 34. 8]
F720 0720
Standard mode
display of extension
panel
0 - 162
*4
--0Y
[5. 4. 3]
[6. 34. 5]
F721 0721 Panel stop
0: Deceleration stop
1: Coast stop
- - 0 Y [6. 34. 9]
F722 0722 Monitor mode filter 8 - 1000 ms 200 Y -
F723 0723
Status area display
of operation panel
0 - 162
*4
--1Y
[5. 4. 3]
[6. 34. 5]
F724 0724
Frequency setting
target by touch
wheel
0: Panel run frequency
command (FC)
1: FC + Preset speed
- - 0 Y [5. 3. 7]
F725 0725
Panel torque
command
-250 to +250 % 0 Y
[6. 25. 1]
[6. 34. 10]
F727 0727
Panel tension
torque bias
-250 to +250 % 0 Y
[6. 25. 3]
F728 0728
Panel load sharing
gain
0 - 250 % 100 Y
F729 0729
Panel override
multiplication gain
-100 to +100 % 0 Y [6. 32]
Title
Communication
No.
Parameter name Adjustment range Unit
Minimum
setting unit
(Panel/
Communication)
Default
setting
Write
during
running
*6
User
setting
Reference

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
