Chapter 5 UCM Wiring and Addressing
90 BMTW-SVN01F-EN
• For LCP supervisor address DIP switch settings, see Table 14 on
page 90.
• For LCP address DIP switch settings, refer to Table 15 on page 92.
Table 14. LCP Supervisor DIP Switch Settings
UCM
Address
DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6 DIP-7 DIP-8
0 OFF OFF OFF OFF OFF OFF OFF OFF
1 on OFF OFF OFF OFF OFF OFF OFF
2 OFF on OFF OFF OFF OFF OFF OFF
3 on on OFF OFF OFF OFF OFF OFF
4 OFF OFF on OFF OFF OFF OFF OFF
5 on OFF on OFFOFFOFFOFFOFF
6 OFF on on OFF OFF OFF OFF OFF
7 onononOFFOFFOFFOFFOFF
8 OFF OFF OFF on OFF OFF OFF OFF
9 on OFF OFF on OFF OFF OFF OFF
10 OFF on OFF on OFF OFF OFF OFF
11 on on OFF on OFF OFF OFF OFF
12 OFF OFF on on OFF OFF OFF OFF
13 on OFF on on OFF OFF OFF OFF
14 OFF on on on OFF OFF OFF OFF
15 on on on on OFF OFF OFF OFF
16 OFF OFF OFF OFF on OFF OFF OFF
17 on OFF OFF OFF on OFF OFF OFF
18 OFF on OFF OFF on OFF OFF OFF
19 on on OFF OFF on OFF OFF OFF
20 OFF OFF on OFF on OFF OFF OFF
21 on OFF on OFF on OFF OFF OFF
22 OFF on on OFF on OFF OFF OFF
23 on on on OFF on OFF OFF OFF
24 OFF OFF OFF on on OFF OFF OFF
25 on OFF OFF on on OFF OFF OFF
26 OFF on OFF on on OFF OFF OFF
27 on on OFF on on OFF OFF OFF
28 OFF OFF on on on OFF OFF OFF
29 on OFF on on on OFF OFF OFF
30 OFF on on on on OFF OFF OFF
31 on on on on on OFF OFF OFF
32 OFF OFF OFF OFF OFF on OFF OFF
33 on OFF OFF OFF OFF on OFF OFF
