Terminal Unit Controller (TUC) Interface
BMTW-SVN01F-EN 107
Table 18. TUC Address Settings
UCM
Address
TUC DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
33 OFF OFF on OFF OFF OFF OFF on
34 OFF OFF on OFF OFF OFF on OFF
35 OFF OFF on OFF OFF OFF on on
36 OFF OFF on OFF OFF on OFF OFF
37 OFF OFF on OFF OFF on OFF on
38 OFF OFF on OFF OFF on on OFF
39 OFF OFF on OFF OFF on on on
40 OFF OFF on OFF on OFF OFF OFF
41 OFF OFF on OFF on OFF OFF on
42 OFF OFF on OFF on OFF on OFF
43 OFF OFF on OFF on OFF on on
44 OFF OFF on OFF on on OFF OFF
45 OFF OFF on OFF on on OFF on
46 OFF OFF on OFF on on on OFF
47 OFFOFFonOFFonononon
48 OFF OFF on on OFF OFF OFF OFF
49 OFF OFF on on OFF OFF OFF on
50 OFF OFF on on OFF OFF on OFF
51 OFF OFF on on OFF OFF on on
52 OFF OFF on on OFF on OFF OFF
53 OFF OFF on on OFF on OFF on
54 OFF OFF on on OFF on on OFF
55 OFF OFF on on OFF on on on
56 OFF OFF on on on OFF OFF OFF
57 OFF OFF on on on OFF OFF on
58 OFF OFF on on on OFF on OFF
59 OFF OFF on on on OFF on on
60 OFF OFF on on on on OFF OFF
61 OFF OFF on on on on OFF on
62 OFF OFF on on on on on OFF
63 OFF OFF on on on on on on
64 OFF on OFF OFF OFF OFF OFF OFF
65 OFF on OFF OFF OFF OFF OFF on
66 OFF on OFF OFF OFF OFF on OFF
67 OFF on OFF OFF OFF OFF on on
68 OFF on OFF OFF OFF on OFF OFF
To Next Page
