Chapter 5 UCM Wiring and Addressing
108 BMTW-SVN01F-EN
69 OFF on OFF OFF OFF on OFF on
70 OFF on OFF OFF OFF on on OFF
71 OFF on OFF OFF OFF on on on
72 OFF on OFF OFF on OFF OFF OFF
73 OFF on OFF OFF on OFF OFF on
74 OFF on OFF OFF on OFF on OFF
75 OFF on OFF OFF on OFF on on
76 OFF on OFF OFF on on OFF OFF
77 OFF on OFF OFF on on OFF on
78 OFF on OFF OFF on on on OFF
79 OFFonOFFOFFonononon
80 OFF on OFF on OFF OFF OFF OFF
81 OFF on OFF on OFF OFF OFF on
82 OFF on OFF on OFF OFF on OFF
83 OFF on OFF on OFF OFF on on
84 OFFonOFFonOFFonOFFOFF
85 OFFonOFFonOFFonOFFon
86 OFFonOFFonOFFon onOFF
87 OFFonOFFonOFFononon
88 OFF on OFF on on OFF OFF OFF
89 OFF on OFF on on OFF OFF on
90 OFF on OFF on on OFF on OFF
91 OFF on OFF on on OFF on on
92 OFF on OFF on on on OFF OFF
93 OFF on OFF on on on OFF on
94 OFF on OFF on on on on OFF
95 OFF on OFF on on on on on
96 OFF on on OFF OFF OFF OFF OFF
Note:
Momentarily short test inputs J11 and J12 after changing switch settings.
Table 18. TUC Address Settings (Continued)
UCM
Address
TUC DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
