VariTrane DDC/VAV UCMs Interface
BMTW-SVN01F-EN 129
Table 24. VAV II, III, and IV Address Settings
VAV II, III, and IV DIP Switch Settings
UCM
Address
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6
65 OFFononononon
66 onOFFonononon
67 OFF OFF on on on on
68 on on OFF on on on
69 OFF on OFF on on on
70 on OFF OFF on on on
71 OFF OFF OFF on on on
72 on on on OFF on on
73 OFF on on OFF on on
74 on OFF on OFF on on
75 OFF OFF on OFF on on
76 on on OFF OFF on on
77 OFF on OFF OFF on on
78 on OFF OFF OFF on on
79 OFF OFF OFF OFF on on
80 on on on on OFF on
81 OFF on on on OFF on
82 on OFF on on OFF on
83 OFF OFF on on OFF on
84 on on OFF on OFF on
85 OFF on OFF on OFF on
86 on OFF OFF on OFF on
87 OFF OFF OFF on OFF on
88 on on on OFF OFF on
89 OFF on on OFF OFF on
90 on OFF on OFF OFF on
91 OFF OFF on OFF OFF on
92 on on OFF OFF OFF on
93 OFF on OFF OFF OFF on
94 on OFF OFF OFF OFF on
95 OFF OFF OFF OFF OFF on
96 on on on on on OFF
97 OFFononononOFF
98 onOFFonononOFF
99 OFF OFF on on on OFF
