Chapter 5 UCM Wiring and Addressing
130 BMTW-SVN01F-EN
100 on on OFF on on OFF
101 OFF on OFF on on OFF
102 on OFF OFF on on OFF
103 OFF OFF OFF on on OFF
104 on on on OFF on OFF
105 OFF on on OFF on OFF
106 on OFF on OFF on OFF
107 OFF OFF on OFF on OFF
108 on on OFF OFF on OFF
109 OFF on OFF OFF on OFF
110 on OFF OFF OFF on OFF
111 OFF OFF OFF OFF on OFF
112 ononononOFFOFF
113 OFF on on on OFF OFF
114 on OFF on on OFF OFF
115 OFF OFF on on OFF OFF
116 on on OFF on OFF OFF
117 OFF on OFF on OFF OFF
118 on OFF OFF on OFF OFF
119 OFF OFF OFF on OFF OFF
120 on on on OFF OFF OFF
121 OFF on on OFF OFF OFF
122 on OFF on OFF OFF OFF
123 OFF OFF on OFF OFF OFF
124 on on OFF OFF OFF OFF
125 OFF on OFF OFF OFF OFF
126 on OFF OFF OFF OFF OFF
127 OFF OFF OFF OFF OFF OFF
Note:
Valid VAV II, III, and IV addresses are 65 to 127.
Table 24. VAV II, III, and IV Address Settings (Continued)
VAV II, III, and IV DIP Switch Settings
UCM
Address
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6
To Next Page
