VariTrane DDC/VAV UCMs Interface
BMTW-SVN01F-EN 131
Table 25. VAV I and IA Address Settings
UCM Address
VAV I & IA DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6
1 OFF on on on on on
2 on OFF on on on on
3 OFFOFFonononon
4 on on OFF on on on
5OFFonOFFononon
6onOFFOFFononon
7 OFF OFF OFF on on on
8 on on on OFF on on
9OFFononOFFonon
10 on OFF on OFF on on
11 O F F O F F o n O F F o n o n
12 on on OFF OFF on on
13 OFFonOFFOFFon on
14 on OFF OFF OFF on on
15 OFF OFF OFF OFF on on
16 on on on on OFF on
17 OFF on on on OFF on
18 on OFF on on OFF on
19 OFF OFF on on OFF on
20 on on OFF on OFF on
21 OFF on OFF on OFF on
22 on OFF OFF on OFF on
23 OFF OFF OFF on OFF on
24 on on on OFF OFF on
25 OFF on on OFF OFF on
26 on OFF on OFF OFF on
27 OFF OFF on OFF OFF on
28 on on OFF OFF OFF on
29 OFF on OFF OFF OFF on
30 on OFF OFF OFF OFF on
31 OFF OFF OFF OFF OFF on
32 on on on on on OFF
33 OFFononononOFF
34 onOFFonononOFF
35 OFF OFF on on on OFF
36 on on OFF on on OFF
