Chapter 5 UCM Wiring and Addressing
132 BMTW-SVN01F-EN
37 OFF on OFF on on OFF
38 on OFF OFF on on OFF
39 OFF OFF OFF on on OFF
40 on on on OFF on OFF
41 OFF on on OFF on OFF
42 on OFF on OFF on OFF
43 OFF OFF on OFF on OFF
44 on on OFF OFF on OFF
45 OFF on OFF OFF on OFF
46 on OFF OFF OFF on OFF
47 OFF OFF OFF OFF on OFF
48 on on on on OFF OFF
49 OFF on on on OFF OFF
50 on OFF on on OFF OFF
51 OFF OFF on on OFF OFF
52 on on OFF on OFF OFF
53 OFF on OFF on OFF OFF
54 on OFF OFF on OFF OFF
55 OFF OFF OFF on OFF OFF
56 on on on OFF OFF OFF
57 OFF on on OFF OFF OFF
58 on OFF on OFF OFF OFF
59 OFF OFF on OFF OFF OFF
60 on on OFF OFF OFF OFF
61 OFF on OFF OFF OFF OFF
62 on OFF OFF OFF OFF OFF
63 OFF OFF OFF OFF OFF OFF
Table 25. VAV I and IA Address Settings (Continued)
UCM Address
VAV I & IA DIP Switch Settings
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6
