DNR-X-1G Series RACKtangle and HalfRACK Systems
Appendix B 110
October 2018 www.ueidaq.com
508.921.4600
© Copyright 2018
United Electronic Industries, Inc.
Figure B-2. Location of Fuses for DNR-POWER-DC Board
Figure B-3. Location of Fuses for DNR-POWER-1GB Board
DNR 120-pin Bus Connector
F1 (5A)
F3 (5A)
F2 (5A)
F4 (5A)
J1
DNA 120-pin Bus Connector
F1 (5A)
F3 (10A)
F2 (5A)
J1
