DQCMD_IOCTL
This command is used to retrieve data from the board. When a port is in
diagnostic mode, it returns current data but cannot reprogram the channel list.
The channel list is used to inform the handler the ID of the channel from which
data should be retrieved.
The following subset of functions, which rely on the DQCMD_IOCTL command
for transport, are supported:
Table 4-2 List of Functions and Associated Boards
Function Associated Board Type(s)
DqAdv201Read AI-201 and AI-202
DqAdv205Read AI-205
DqAdv207Read AI-207
DqAdv225Read AI-225
DqAdv3xxWrite AI-302/308 and AI-332
DqAdv40xRead DIO-401/405/404/406
DqAdv403Read DIO-403
DqAdv416GetAll DIO-416 -- Voltage, current, and circuit
breaker state monitoring
DqAdv432GetAll DIO-432 -- Voltage, current, and circuit
breaker state monitoring
DqAdv448Read DIO-448
DqAdv448ReadAdc DIO-448 -- Voltage monitoring
DqAdv501GetStatistics SL-501and SL-508 -- Received/error counters
DqAdv566GetStatistics ARINC-429-566 -- Received/error counters
DqAdv601Read CT-601 -- Counters, states of input lines
DqAdv604Read QUAD-604 -- Positions, states of input lines
