Page #11 background imageLoading...
Page #11 background image
DNR-X-1G Series RACKtangle and HalfRACK Systems
Chapter 1 3
Introduction
October 2018 www.ueidaq.com
508.921.4600
© Copyright 2018
United Electronic Industries, Inc.
1.2 Product
Versions
Described in
This Manual
This user manual provides documentation for the DNR-X-1G series data
acquisition systems: DNR-X-1G, DNR-X-1G-02, and DNR-X-1G-03 product
versions.
Each product version is available in a DNR-12-1G RACKtangle chassis or a
DNR-6-1G HalfRACK chassis.
Table 1-1 below provides a summary of features for each product version. Refer
to the following chapters in this manual for detailed descriptions.
NOTE: Unless otherwise noted, DNR-X-1G refers collectively to the
DNR-X-1G(-00/-01), DNR-X-1G-02, and DNR-X-1G-03 series of
products.
Table 1-1 Summary of DNR-X-1G/DNR-X-1G-XX Product Versions
Item Summary of Features
DNR-X-1G
(DNR-X-1G-00 /
DNR-X-1G-01)
10/100/1000Base-T Ethernet interface
Freescale MPC8347 CPU
1PPS synchronization support
1
128 MB RAM
2
32 MB flash memory
2
DNR-X-1G-02 10/100/1000Base-T Ethernet interface
Freescale MPC8347 CPU
1PPS/IEEE-1588 synchronization support
1
Optional solid-state hard drives
3
256 MB RAM
2
32 MB flash memory
2
DNR-X-1G-03 10/100/1000Base-T Ethernet interface
Freescale MPC8347E CPU, (encryption-ready / IPSec support
pending)
1PPS/IEEE-1588 synchronization support
1
Optional solid-state hard drives
3
256 MB RAM
2
128 MB flash memory
2
1.1PPS and IEEE-1588 synchronization support is described in the PowerDNx 1PPS Sync Interface Manual.
2.RAM and flash memory are not user-accessible for PowerDNA applications (hosted deployment). Portions
of RAM and flash are available for UEIPAC-based systems (stand-alone deployment). See UEIPAC docu-
mentation for more information.
3.On UEIPAC-based systems (stand-alone deployment), solid state drives are used for data and/or root file
system storage.See UEIPAC documentation for more information.
