DNR-X-1G Series RACKtangle and HalfRACK Systems
Chapter 2 12
The DNR-12-1G Series RACKtangle System
October 2018 www.ueidaq.com
508.921.4600
© Copyright 2018
United Electronic Industries, Inc.
Figure 2-8. DNR Board Ejection/Insertion Lever Operation
Lift Lever
to eject
board from
backplane
connector
Press lever
down to
insert board
into
backplane
connector
DNR Backplane Connector
