UEi RACKtangle DNR-12-1G Series User Manual

DNR-X-1G Series RACKtangle and HalfRACK Systems
Chapter 2 11
The DNR-12-1G Series RACKtangle System
October 2018 www.ueidaq.com
508.921.4600
© Copyright 2018
United Electronic Industries, Inc.
2.4.2.2 DNR-IO-
FILLER, DNR-
BRACKET, &
DNR- I/O
Board
Drawings
The following section provides drawings for the DNR-IO-FILLER,
DNR-BRACKET, and DNR- I/O board extraction lever as found in DNR-X-1G
systems.
Figure 2-6. Optional DNR-IO-Filler Panel for Empty Slots
Figure 2-7. DNR-BRACKET Reversible Mounting Bracket
Grounding
Fingers
Turn bracket upside down
to use as surface or flange
mounted device

UEi RACKtangle DNR-12-1G Series Specifications

General

Brand	UEi
Model	RACKtangle DNR-12-1G Series
Category	Network Hardware
Language	English
