UEi RACKtangle DNR-12-1G Series User Manual

DNR-X-1G Series RACKtangle and HalfRACK Systems
Chapter 2 10
The DNR-12-1G Series RACKtangle System
October 2018 www.ueidaq.com
508.921.4600
© Copyright 2018
United Electronic Industries, Inc.
2.4.2.1 Physical
Addressing of
DNR-12-1G
Components
A feature of the DNR-X-1G design is that the address of a module is determined
by the position of the module within the enclosure, numbered from left to right. A
typical module address is:
0xA00nxxxx
where A00 is the BASE address
n is the module position number starting from 0 at the left
xxxx is the address of the module
With this addressing method, the address of a given I/O board (module)
automatically changes if you move it from one position to another within the
enclosure.
The slots or module positions are numbered as follows (left to right):
Physical Position Position Number Module Description
10xC POWER-DC
2 0x0 I/O Board 1
3 0x1 I/O Board 2
4 0x2 I/O Board 3
5 0x3 I/O Board 4
6 0x4 I/O Board 5
7 0x5 I/O Board 6
80xD
0xE
POWER-1GB
CPU/NIC
9 N/A BUFFER
10 0x6 I/O Board 7
11 0x7 I/O Board 8
12 0x8 I/O Board 9
13 0x9 I/O Board 10
14 0xA I/O Board 11
15 0xB I/O Board 12
