DNR-X-1G Series RACKtangle and HalfRACK Systems
Chapter 2 5
The DNR-12-1G Series RACKtangle System
October 2018 www.ueidaq.com
508.921.4600
© Copyright 2018
United Electronic Industries, Inc.
A standard DNR-12-1G rack system consists of the following:
• One or more DNR-12 rack mounted enclosure(s)
• DNR-POWER-DC Power Module (one for each enclosure)
• DNR-CPU-1000 or DNR-CPU-1000-XX Module
(Freescale MPC8347 or MPC8347E CPU and 1-GB Ethernet
1000 Base-T Network Interface Module — one for each enclosure)
• DNR-BUFFER Board Module (one for each enclosure)
• Optional DNR-IO-FILLER panels (one for each unused I/O slot)
Note: These slot covers are optional and not included in the price of the
rack
• DNA-PSU-180 180-Watt, 120/230 VAC to +24 VDC External Power
Supply (one for each enclosure) with cable and Molex connector for
plug-in to the DNR-POWER-DC Module front panel
To configure a complete data acquisition system, insert up to 12 DNR I/O boards
into each PowerDNR rack enclosure. I/O boards may be specified in any
combination of UEI’s I/O boards.
All standard PowerDNA accessories are also available for use in a PowerDNR
rack-mount system.
NOTE: For detailed descriptions of all I/O boards and accessories available for
DNR-X-1G systems, refer to www.ueidaq.com.
UEI stand-alone systems (UEIPAC, UEISIM, UEIModbus, and UEIOPCUA
deployments) are also available for use with DNR-12-1G RACK systems:
• UEIPAC 1200R - Programmable Automation Controller
• UEISIM 1200R - Simulink / Simulink Coder Target
• UEIModbus 1200R - Modbus TCP-based Controller
• UEIOPCUA 1200R - OPC-UA Server, accessed by any OPC-UA client
