DNR-X-1G Series RACKtangle and HalfRACK Systems
Chapter 3 31
The DNR-6-1G Series HalfRACK System
October 2018 www.ueidaq.com
508.921.4600
© Copyright 2018
United Electronic Industries, Inc.
3.4.2.1 Physical
Addressing of
DNR-6-1G
Components
A feature of the DNR-6-1G design is that the address of a module is determined
by the position of the module within the enclosure, numbered from left to right. A
typical module address is:
0xA00nxxxx
where A00 is the BASE address
n is the module position number starting from 0 at the left
xxxx is the address of the module
With this addressing method, the address of a given I/O board (module)
automatically changes if you move it from one position to another within the
enclosure.
The slots or module positions for the DNR-6-1G are numbered as follows (left to
right:
Physical Position Position Number Module Description
10xCPOWER-DC
20xD
0xE
POWER-1GB
CPU/NIC
3 0x0 Module1
4 0x1 Module2
5 0x2 Module3
6 0x3 Module4
7 0x4 Module5
8 0x5 Module6
