Unify OpenScape CP600 User Manual

12
Icons used in the manual
Tips
z Refers to a setting established via the web-interface.
Displays for describing operation
Selected action
Original illustration on display
Step-by-step illustration in the User Guide
A dark background is not used in the step-by-step illustration in order to ensure
legibility in the User Guide.
The information area on the left is shown in a left-aligned field.
When an action is selected, it will be shown right-aligned in green. The action is
executed by selecting the Softkey.
Z The selected function can alternatively be confirmed using the Z key on the
navigator ( page 20).
Indicates additional important information in relation to handling.
ñ
Indicates required intervention by the administrator.
accept
Decline call
Andre-Marie Ampere
3336
Ankommender Ruf
t Ankommender Ruf
Andre-Marie Ampere
3336
accept
O
_

Unify OpenScape CP600 Specifications

General

Ethernet Ports	2 x 10/100/1000 Mbps
HD Voice	Yes
Display	Color TFT Display
Resolution	480 x 272 pixel
Connectivity	Gigabit Ethernet
Audio	HD Voice
Keys	4-way navigator key
Power	PoE (802.3af)
Protocols	SIP
Headset	EHS
USB Port	USB 2.0
Bluetooth	Optional
Supported Codecs	G.711, G.722, G.729
