Unify OpenScape CP600 User Manual

13
Action not selected
Illustration on display
Step-by-step illustration in the User Guide
If an action is not selected, it is shown right-aligned in a light color. The associ-
ated Softkey is also shown. The action can be executed by pressing the softkey
without the action being selected.
Conversation display
When the phone is idle, the first entry in the conversation list is selected.
Information displayed for a selected conversation
If a conversation (contact and history at the same time) is selected in the list, it
is highlighted in green. This description is only used if it aids understanding. This
is the usually what is displayed:
accept
Decline call
Andre-Marie Ampere
3336
Ankommender Ruf
Decline call
P
_
Conversations
Daniel Bernoulli
b Received call {1}(1:35:50)
9:44
Andre-Marie Ampere
b Received call {1}(45:56)
8:45
Georg Simon Ohm
Isaac Newton
-
Daniel Bernoulli - 11:22
O
c
Received call {1} (1:35:50)

Unify OpenScape CP600 Specifications

General

Ethernet Ports	2 x 10/100/1000 Mbps
HD Voice	Yes
Display	Color TFT Display
Resolution	480 x 272 pixel
Connectivity	Gigabit Ethernet
Audio	HD Voice
Keys	4-way navigator key
Power	PoE (802.3af)
Protocols	SIP
Headset	EHS
USB Port	USB 2.0
Bluetooth	Optional
Supported Codecs	G.711, G.722, G.729
