Unify OpenScape CP600 User Manual

97
Spoken via loudspeaker
You are being spoken to directly by a colleague over speakerphone. Before this
happens you will hear an alert tone. The partner's name or phone number is
shown on the display. You can answer directly with the handset or via loudspe-
aker .
^ Lift handset and answer.
or
Confirm.
or
Æ Press the illuminated microphone key.
Microphone on
_
When answering hands-free (see below), upon answering you must not
switch on the microphone. You can answer hands-free immediately.
If hands-free answering is blocked (default), proceed as described above.
Speak directly to your colleagues  page 104.

Unify OpenScape CP600 Specifications

General

Ethernet Ports	2 x 10/100/1000 Mbps
HD Voice	Yes
Display	Color TFT Display
Resolution	480 x 272 pixel
Connectivity	Gigabit Ethernet
Audio	HD Voice
Keys	4-way navigator key
Power	PoE (802.3af)
Protocols	SIP
Headset	EHS
USB Port	USB 2.0
Bluetooth	Optional
Supported Codecs	G.711, G.722, G.729
