DNS na me : Name or number of telephone.
URL: HTTP address of the web interface. This address is specified in the ad-
dress line of the Internet browser and is used to call up the web interface of the
phone in the browser.
IPV4 Address: Display of the IP address or name that was assigned to the pho-
ne in the network.
LAN-RX/PC-RX: The network or PC interface data packets received are illustra-
ted dynamically in graphical form.
LAN-TX/PC-TX: The network or PC interface data packets sent are illustrated
dynamically in graphical form.
LAN autonegotiation/PC autonegotiation [Yes)|No]: Displays whether the
network or PC interface data transfer rate is set to automatic (Yes) or manual
(No).
LAN information/PC information: [10|100|1000] Mbit/s: Data transfer rate of
the network or PC interface. If an interface is not in use, Link down is displayed.
PC-RX
PC-TX
LAN autonegotiation Yes
LAN information.100 Mbps, full duplex,Gigabit enabled
Network information
Network information
LAN information.100 Mbps, full duplex,Gigabit enabled
PC autonegotiation
PC information Link down
Yes
LAN autonegotiation Yes

Unify OpenScape CP600 Specifications

General

Ethernet Ports	2 x 10/100/1000 Mbps
HD Voice	Yes
Display	Color TFT Display
Resolution	480 x 272 pixel
Connectivity	Gigabit Ethernet
Audio	HD Voice
Keys	4-way navigator key
Power	PoE (802.3af)
Protocols	SIP
Headset	EHS
USB Port	USB 2.0
Bluetooth	Optional
Supported Codecs	G.711, G.722, G.729
