Chapter 5 __________________________________________ Software Configuration and Operation
VAISALA______________________________________________________________________ 111
Software Configuration Procedure
CAUTION
Configure AWS330 by following this procedure step by step.
NOTE
Navigating in the screens is explained in section General Instructions on
Using AWS Client on page 104. Read it carefully.
1. Set Common Parameters as described on page 112.
2. Set Location Parameters as described on page 113 (optional).
3. Set time as described in section Time and Time Zone on page 114.
4. Set Sensor Parameters as described on page 116.
5. Select the message type you want to use with AWS330. For
message type descriptions, see section Observation Messages on
page 27.
6. Set message transm
ission interval for the selected message type as
described in section Message Intervals on page 118.
7. Select observation me
ssaging protocols(s) as described in section
Messaging Protocols on page 119.
8. Select alarm messaging protocol(s) as described in section
Alarming Protocols on page 121.
9. Set messaging protocol -dependent parameters. Based on the
protocol(s) chosen in steps 7 and 8, refer to following section(s):
- TCP-Socket (Virtual Com Port) on page 122.
- File Transfer Protocol (FTP) on page 124.
- eMail (SMTP) on page 126.
- GSM SMS on page 129.
- Local Serial Line on page 130.
- For CSD dial-in, there is no protocol-dependent configuration
required.
10. Set up telemetry configuration:
-
For IP over GPRS telemetry, see section GSM Modem on page
131 and GPRS on page 132.
- For data call telem
etry, see section GSM Modem on page 131
and CSD Dial-In (Data Call) on page 134.
- For IP over Ethernet telemetry, see section Ethernet on page
135.
11. Set up alarm limits as described in Alarms on page 136.
12. To make param
eter updates effective, reset the AWS330 system
using AWS Client. From the AWS Client menu, select
Maintenance - Reset - Immediate.
