Chapter 5 __________________________________________ Software Configuration and Operation
VAISALA______________________________________________________________________ 135
Ethernet
AWS Ethernet board does not require any configuration. IP connection
established over it uses the following parameters:
NOTE
By default, Ethernet is brought up when AWS starts, and it uses a
dynamic IP address obtained from the DHCP server. The dynamic
address can be checked using RS232 service connection to COM0 and
issuing command ipconfig.
1012-167
Figure 80 IP Settings for Ethernet
Table 34 Ethernet Connection Parameters
Set Name Parameter Name Use
eth1 Staticip Static IP in use. 0 = No, 1 = Yes
(1
eth1 Address AWS IP address
(1
eth1 Subnetmask Network mask
(1
eth1 Gateway Default gateway
(1
eth1 dns1 Domain name server 1
(1
eth1 dns2 Domain name server 2
(1
eth1 Autoinit Bring interface automatically up when
AWS starts, and attempt to keep always
open. Otherwise, interface is opened
only when needed.
(1
Using static IP has to be approved by the organization operating the
network.
