User's Guide ______________________________________________________________________
122 _________________________________________________________________ M211296EN-A
Protocol Parameters
Parameters required to configure different application-level protocols
used for messaging are described in the following sections. Parameters
for unused protocols must be left unchanged.
TCP-Socket (Virtual Com Port)
TCP-socket connection allows messages to be sent to data acquisition
server hosting one or multiple TCP- server sockets, where QML loggers
can connect to as TCP-client.
1101-020
Figure 71 Example TCP-Socket for Message Transmission
NOTE
Raw TCP-sockets are commonly subject to blocking by firewalls.
Therefore, opening ports in one or more firewalls may be required.
1011-022
Figure 72 Setting TCP-Socket Parameters
