Chapter 8 ____________________________________________________________ Technical Data
VAISALA______________________________________________________________________ 253
Communication Modules
RS-485 Module
Table 90 Dual-Isolated RS-485 Communication Module DSI486
Specifications
Property Description/Value
Channels
Channel A
Channel B
RS-485
RS-232 or RS-485
SDI SDI-12
Isolation Galvanic
Operating modes Two 2-wire RS-485 and SDI-12
2-wire RS-485, RS-232, and SDI-12
Power consumption
Idle
Operating
2.8 ... 4.3 mA
10.6 ... 12.4 mA
Connection distance (max.) 1500 m (4900 ft.)
Temperature (operating) -40 ... +60 °C (-40 ... +140 °F)
Temperature (storage) -50 ... +70 °C (-58 ... +158 °F)
Humidity 0 ... 100 %RH
Ethernet Communication Module DSE101
Table 91 Ethernet Communication Module DSE101
Specifications
Property Description/Value
Operating mode 10Base-T
Power consumption
(transmitting)
50 mA at 12 V
Temperature Normal: -40 ... +70 °C (-76 ... 158 °F)
Extended: -60 ... +70 °C (-76 ... 158 °F)
Humidity 0 ... 100 %RH
