Vaisala AWS330 - File Transfer Protocol (FTP)

User's Guide ______________________________________________________________________
124 _________________________________________________________________ M211296EN-A
File Transfer Protocol (FTP)
FTP enables QML logger to send messages as files to FTP server.
Internet
Ethernet
LAN
Firewall
FTP Server
ADSL
switch
ISP
(DSLAM)
PSTN
1101-021
Figure 73 Example FTP Transmission
Messages appear in FTP server as single file per message, in the
following directory structure, and named as:
<FTP root>
<AWS Home>
<Station Name>
Obs_FTP<YYMMDDhhmmss>.rep
where
<FTP root> = Root directory defined for FTP server
<AWS Home> = User home directory defined for AWS login
<Station Name> = Station name as set to QML logger
<YYMMDDhhmmss> = Message creation timestamp UTC
Example filename:
Obs_FTP101123132213.rep
- Message was created at 2010/11/23 13:22:13 UTC
