Installing Ultrasonic Wind Sensor WMT703
Ultrasonic Wind Sensor WMT703 measures wind speed and direction.
WMT703 is installed on top of the mast with the FIX70 mounting kit.
The sensor is shipped in a custom cardboard container with plastic
transportation dampers. When unpacking WMT703, remove only the
damper that protects the sensor body. Do not remove the damper that
protects the array.
CAUTION
Do not remove the transportation damper that protects the array until you
have installed WMT703.
1012-215
Figure 25 Removing WMT703 Transportation Damper
NOTE
Save the container and all the packaging materials for future transporting
or shipping.
