Enclosure
Table 86 Large Stainless Steel Enclosure Specifications
Property Description/Value
Material Stainless steel
Protection rating IP 66, equivalent with NEMA 4X
Maximum dimensions including
radiation shield (h × w × d)
615 × 520 × 263 mm
(24.2 × 20.5 × 10.4 in.)
Weight without radiation shield 13.7 kg (30.2 lb)
Wall mounting By four M8 × 15 mm screws from rear side
Temperature range -50 … + 100 °C (-58 ... +212 °F)
Displays
Local LCD Display QMD202 (Optional)
Table 87 Local LCD Display QMD202 Electrical Specifications
Property Description/Value
Interface SPI
Input voltage Vin 3.3 and 5.0 VDC powered from QML data
logger
Power consumption
Backlight OFF
Backlight ON
20 mW
85 mW
Connector Connected to and powered by QML data
logger via 10-wire flat cable
Table 88 Local LCD Display QMD202 Mechanical
Specifications
Property Description/Value
Dimensions 127 × 95 × 29 mm
Weight 230 g
Mounting NS35 DIN rail foot
Enclosure material Aluminum
LCD Display size (width ×
height)
20 × 6 characters
Table 89 Local LCD Display QMD202 Environmental
Specifications
Property Description/Value
Operating temperature -25 ... +60 °C
Storage temperature -60 ... +60 °C
Regulatory compliances IEC(EN)-61326-1, for use in industrial
locations
Vibration IEC 60068-2-6, level 2 g
