Chapter 8 ____________________________________________________________ Technical Data
VAISALA______________________________________________________________________ 237
CHAPTER 8
TECHNICAL DATA
This chapter provides the technical data of AWS330.
Wiring
QML Logger QML201C
The QML logger includes:
1. Ten measurement channels and one internal channel for pressure
measurement.
2. One connector block for power supplies.
3. One connector block for communication channels.
4. Two blocks for optional communication modules.
Single-ended (H-C or L-C) or differential (H-L) measurements can be
performed in the 10 measurement channels.
NOTE
Each sensor in a basic setup has its own dedicated channel. Table 70 on
page 238 is to be used for reference purposes only.
