Chapter 8 ____________________________________________________________ Technical Data
VAISALA______________________________________________________________________ 247
Table 75 QML201C Logger Regulatory Compliances
Property Description/Value
Emissions CISPR 22 class B (EN55022)
ESD immunity IEC 61000-4-2
RF field immunity IEC 61000-4-3
EFT immunity IEC 61000-4-4
Surge (lightning pulse) IEC 61000-4-5
Conducted RF immunity IEC 61000-4-6
Barometric Pressure
Table 76 Pressure Sensor BARO-1 Specifications
Property Description/Value
Sensor type Vaisala BAROCAP® (silicon capacitive)
Measuring range 500 ... 1100 hPa
Resolution 0.1 hPa
Operating temperature -40 ... +60 °C (-40 ... 140 °F)
AC (Mains) Power Supply
Table 77 AC (Mains) Power Supply Specifications
Property Description/Value
Output power 60 W
Operating principle SMPS
Input voltage range 90 … 264 VAC
Frequency range 45 ... 65 Hz
Input current on full load:
115 VAC 1.2 A
230 VAC 0.7 A
Output voltage +15 VDC, adjustable 13 ... 18 VDC
Output current 4.0 A
Efficiency 80 % min.
Installation Removable installation plate
Operating temperature
range
-40 ... +55 °C (-40 ... +131 °F)
