User's Guide ______________________________________________________________________
258 _________________________________________________________________ M211296EN-A
Table 103 General
Property Description/Value
Heating Transducer heating 30 W
Operating temperature
-55 ... +70 °C
Operating voltage
Absolute maximum
9 ... 36 VDC
40 VDC
Heating voltage
Typical ranges
Absolute maximum
24 ... 36 VDC
40 VDC
IP class IP66/IP67
Material
Body
Transducers
Mounting kit
Stainless steel AISI316
Silicone
Stainless steel AISI316
Dimensions (h × w × d) 350 mm h × 250 mm × 285 mm
Weight 2 kg
Connector Hummel 7.106 series
Dimensions
Figure 134 below and Figure 135 on page 259 show the dimensions of
Ultrasonic Wind Sensor WMT703 and Mounting Kit FIX70.
1001-015
Figure 134 Ultrasonic Wind Sensor WMT703 Dimensions in
Millimeters
