User's Guide ______________________________________________________________________
164 _________________________________________________________________ M211296EN-A
1011-009
Figure 102 Soil State Display
Table 46 Soil State Display Parameters
Heading Parameter Unit Statistic Period
SN Snow depth cm Average 1 min
TS1 Soil/water temperature 1 °C Average 10 min
TS2 Soil/water temperature 2 °C Average 10 min
1011-010
Figure 103 System Status Display
Table 47 System Status Display Parameters
Heading Parameter Unit Statistic Period
DC DC supply voltage V n/a 1 min
T Internal temperature °C n/a 1 min
Cfg Configuration version n/a n/a n/a
SW Firmware version n/a n/a n/a
HW Hardware version n/a n/a n/a
1011-011
Figure 104 Network Status Display
Table 48 Network Status Display Parameters
Heading Parameter
IP IPV4 address
SN Subnet mask
GW Default gateway
D1 Domain name server 1
D2 Domain name server 2
