Vaisala PR-23 Series User Manual

Model Description
‑EP Electropolished sensor wetted parts (RA 0.38 µm, 15 µin)
1)
1) For AISI 316 L / EN 1.4335 only.
2)
Includes gasket Teflon 2.5 in and Ferrule in Alloy C.
3) Available with STR Indicating Transmitter and IS isolator only.
4) For ‑H, ‑E, ‑N options.
10.3.2 PR‑23‑A
C mounting hardware model code
Table 13 Elbow flo
w cells for PR‑23‑AC‑xx‑HSS sensor
Model Description
AFC Elbow flo
w cell
Sensor connection
‑H Sanitary clamp, 2.5 in
Material of construction
SS AISI 316 L
Process connection
‑H Sanitary clamp
Pipe section diameter
10 25 mm (1 in)
15 40 mm (1.5 in)
20 50 mm (2 in)
25 65 mm (2.5 in)
1)
30 80 mm (3 in)
1)
40 100 mm (4 in)
1)
Flow cell inlet type
‑SI Straight pipe
‑RI Reduced pipe (cone)
Polishing option
‑EP Electropolished process wetted parts (RA 0.38 µm, 15 µin)
1) With ‑SI option only.
PR-23 Series User Guide
IM-EN-PR23-E
102
