Vaisala PR-23 Series User Manual

10.6.4 PR‑23‑GP parts lis
t
1
2
3
4
25
26
5
6
27
7
8
9
10
11
13
12
13
14
15
16
17
18
23
19
20
21
22
24
Item Pcs. Part No. Descrip�on
1.1
1
PR-10009
PR-23-GP-L head
1.2
1
PR-10010
PR-23-GP-D head
1.3
1
PR-10011
PR-23-GP-D-NC head
Item
Pcs.
Part No.
Descrip�on
12
1
PR-10103
Sensor processor card
2
1
ANSI 3” 150 lbs flange
13
8
Screw M3x6 DIN 912 A2
2
1
DIN 80 PN 25 flange
14
1
PR-10300
Bus terminator card
2
1
JIS 80A 10k flange
15
1
PR-10032
O-ring seal 24x2
16
1
PR-9108
Dryer sachet
3
1
PR-10048
68x3 O-ring
17
1
PR-10031
O-ring seal 89.5x3
4
1
Alignment pin
18.1
1
PR-10000
PR-23 cover
5.1
1
PR-10005
PR-23 base
18.2
1
PR-10000-SC
PR-23 cover SS
5.2
1
PR-10005-SC
PR-23 base SS
18.3
1
PR-10000-EC
PR-23 cover EC
5.3
1
PR-10005-EC
PR-23 base EC
19
4
Screw M4x30 DIN 912 A4
6
6
Screw M5x12
20
1
PR-10002
O-ring seal 82x3
6
Locking spacer M5
21
1
PR-23 endplate with label
7
1
PR-10022
PR-23-P core
22
4
Screw M4x8 DIN 964 A4
8
1
PR-9011
Thermal conductor
23
1
Cable gland M16x1.5
*
1
PR-9010
Disc spring set
24
1
Label
9
2
Disc spring
25
2
Screw M6x30 A4 DIN912
10
1
Disc spring holder
26
2
Washer M6 A4 DIN125
11
6
Screw M5x10 DIN 912 A2
27
6
Lock washer M6
Figure 69 PR‑23‑GP parts list
PR-23 Series User Guide
IM-EN-PR23-E
136
