Vaisala PR-23 Series User Manual

PROC ESS INSTRUMENTS
POW ER
S traight-through
cable
LAN
Figure 121 Connecting DTR to LAN
If y
ou are connecting the DTR to a hub or switch or WLAN access point, please consult the
user guide of your hub/switch/access point for the correct cable type, as shown in the
following figures.
PROC ESS INSTRUMENTS
POW E R
Hub/Switch
Check hub/switch manual
for Ethernet cable type
Figure 122 Connecting DTR to hub or switch
PROC ESS INSTRUMENTS
POW E R
WLAN
Access
point
Check WLAN manual
for Ethernet cable type
Figure 123 Connecting DTR to WLAN
If you need a longer cable or the environment is electrically noisy, use fiber
optics Ethernet
with media converters as shown in the following figure.
PR-23 Series User Guide
IM-EN-PR23-E
228
