A factory acceptance test (FAT), and customized drawings stating client specific information
are also available on request.
10.7.1 PR23RP sensor model code
Table 36 PR23RP sensor model code
Model Description
PR23 Sensor
Sensor model
R Refinery
Sensor type
P Probe type, wetted materials single piece no weldings
Refractive index range limits
73 R.I. 1.320–1.530 n
D
(0 … 100 Brix) sapphire prism
Process connection
M20 ANSI-flange 300 lbs, 2 in, insertion length 130 mm
J20 JIS-flange 10k 50A, insertion length 130 mm
Sensor wetted parts material
SS AISI 316 L
HA Alloy 20
HC Alloy C276
Electrical classification
AX ATEX and IECEx certified Ex II 3G, Ex nA IIC T4 Gc (up to zone 2) (T
amb
−20 … +65 °C)
IA ATEX and IECEx certified Ex II 1G, Ex ia IIC T4 Ga (up to zone 0) (T
amb
−20 … +65 °C)
1)
CX NEPSI Certified for use in Ex nA IIC T4 Gc
CI NEPSI Certified for use in Ex ia IIC T4 Ga
Sensor housing
SC Stainless steel AISI 316
1) Available with STR indicating transmitter and IS isolator only.
Example: Sensor: PR23RP73M20SSAXSC
Chapter 10 – Sensor specifications
139
