14. Interconnecting cable
14.1 Interconnecting cable model code
Table 60 Interconnecting cable model code
Part number Description
PR-8230 Interconnecting cable between transmitter and sensor
Cable length
-010
-_ _ _
• 10 m (33 ft), standard length
•
Specify cable length in meters with 10 meter increments
Max. length is 200 m (660 ft)
14.2 Interconnecting cable specifica
tions
Table 61 Interconnecting cable specifica
tions
Feature Specification
Cable IEC 61158‑2 compliant two-wire cable: two signal
wires and shield copper area 0.8 mm
2
(18 AWG) cable
resistance 24 Ω/km (per wire) cable attenuation
3.0 dB/km @ 28 kHz
Cable length Standard 10 m (33 ft), max. total length 200 m
(660 ft)
For information on the intrinsically safe cabling for PR‑23‑…
‑IA/‑CI, see Intrinsically safe
mounting (page 165).
