Vaisala PR-23 Series - Table 24 Side Flow Cells, Connection Sanitary Clamp 2.5 in; Table 25 Aseptic Steam Valve for PR-23-AP-ISS

Model Description
‑SN Integral steam nozzle, AISI 316 L
‑WP Integral pressurized water nozzle, AISI 316 L
‑WN Integral water nozzle, AISI 316 L
Table 24 Side flow cells, connection sanitary clamp 2.5 in
Model Description
SFC Side flow cell
1)
Sensor connection
‑HH Sanitary clamp, 2.5 in
Material of construction
SS AISI 316 L
Pipe section diameter
10 25 mm (1 in)
15 40 mm (1.5 in)
20 50 mm (2 in)
25 65 mm (2.5 in)
Flow cell inlet and outlet orientation
‑090 Elbow, 90 ° bend
‑180 Straight pipe, 180 °
1) Includes one 2.5 in blind flange with 2.5 in EPDEM gasket and 2.5 in sanitary clamp.
Table 25 Aseptic steam valve for PR‑23‑AP‑ISS
Model Description
ASV
Aseptic steam valve
1)
Sensor connection
‑H Sanitary clamp, 2.5 in
‑E Varinlineâ in‑line access unit clamp 2 in (DN 50/40)
Material of construction
SS AISI 316 L
Option
‑ASI With AS interface control head (30 VDC)
Chapter 10 – Sensor specifications
117
