11.3 Safe‑Driv
e component parts lists
11.3.1 PR-23-SD sensor
3
4
6
7
8
9
12
13
14
15
19
20
21
1
5
10
11
13
16
17
18
23
22
Item
Pcs.
Part No.
Descrip�on
Item
Pcs.
Part No.
Descrip�on
1
1
PR-10015
PR-23-SD head
11 6 Screw M5x10 DIN 912 A2
2 1 Safe-Drive™ flange
12
13
1
8
PR-10101
Sensor processor card
Screw M3x5 DIN 7380 A4
3
4
5
6
7
8
*
9
10
1
1
1
6
1
1
1
2
1
PR-10048
PR-10005
PR-10022
PR-9011
PR-9010
68x3 O-ring
Alignment pin
PR-23 base
Screw M5x10 DIN 912 A2
PR-23-P core
Thermal conductor
Disc spring set
Disc spring
Disc spring holder
14
15
16
17
18
19
20
21
22
23
1
1
1
1
1
4
1
1
4
1
PR-10300
PR-9108
PR-10000
PR-10002
Bus terminator card
O-ring seal 24x2
Dryer sachet
O-ring seal 89.5x3
PR-23 cover
Screw M4x30 DIN 912 A4
O-ring seal 82x3
PR-23-SD endplate with label
Screw M4x8 DIN 964 A4
Cable gland M16x1.5
Figure 93 PR-23-SD sensor parts
