Vaisala PR-23 Series User Manual

10.8.3 PR‑23‑M parts lis
t
8
35
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Item
Pcs.
Part No.
Descrip�on
Item
Pcs.
Part No.
Descrip�on
1
4
Screw DIN 7991 M5x70 A4
18
1
PR-10036
PR-23 compact sensor CORE module
2
1
PR-23-M endplate
19
1
PR-9011
Thermal conductor
3
1
PR-9129
PR-03/23-M protec�on cover
*
1
PR-9010
Disc spring set
4
1
Screw DIN 912 M4x10 A4
20
2
Disc spring
5
1
PR-9120
PR-03/23-M-PV-R05 flow cell (PVDF)
21
1
Disc spring holder
5
1
PR-9121
PR-03/23-M-TF-R05 flow cell (PTFE)
22
6
Screw DIN 912 M5x12 A2
6
1
PR-9252
O-ring 20.2 x 3 Kalrez 6375UP
23
1
PR-10103
Sensor processor card
7
6
Screw M4 x 20 DIN 7991 A4
24
4
Screw M3x6 DIN 912 A2
8
1
PR-03/23-M headring (PVDF)
25
4
Screw M3x6 DIN 912 A2
9
1
PR-9112
O-ring seal 30.3 x 2.4 FPM
26
1
PR-10300
Bus terminator card
10
1
PR-9126
Sapphire plate for PR-03/23-M
27
1
PR-9108
Dryer sachet
11
1
PR-9113
O-ring seal 37.3 x 3 FPM
28
1
PR-10032
O-ring seal 24 x 2
12
1
PR-9100
Sensor support
29
1
PR-10000
PR-23 cover
13
1
PR-11101
PR-23-M head
29
1
PR-10000-EC
PR-23-EC cover
14
1
PR-10048
68x3 O-ring
30
4
Screw M4x30 DIN 912 A4
15
1
Alignment pin
31
1
PR-10002
O-ring seal 82x3
16
1
PR-10005
PR-23 base
32
1
Cable gland M16x1.5
16
1
PR-10005-EC
PR-23-EC base
33
1
PR-23-M endplate with label
17
6
Screw M5x12 DIN 912 A2
34
4
Screw M4x8 DIN 964 A4
6
Locking spacer M5
35
1
PR-10031
O-ring seal 89.5 x 3
Figure 79 PR‑23‑M parts lis
t
10.8.4 PR‑23‑MS sensor model c
ode
Table 44 PR‑23‑MS sensor model c
ode
Model Description
PR‑23 Sensor
Sensor model
‑M Aggressive medium adapter
S Semiconductor industry
PR-23 Series User Guide
IM-EN-PR23-E
150
