Model Description
IF FM certified to US and Canadian standards Class I, Div.1, Groups A, B, C, D T4 (T
amb
−20 … +45 °C)
1)
CX NEPSI Certified for use in Ex nA IIC T4 Gc
CI NEPSI Certified for use in Ex ia IIC T4 Ga
Sensor housing
AA Anodized Aluminum
SC Stainless steel AISI 316
Prism wash
SN Integral steam nozzle
WN Integral water nozzle
WP Integral pressurized water nozzle
NC Integral nozzle connection
YC Without nozzle connection option
Option
VD Vertical Borderline Image Detection (for example, sugar vacuum pan)
1) Available with STR Indicating Transmitter and IS isolator only.
10.6.2 PR23GP specifications
Table 34 General specifications
Feature Specification
Refractive index range Full range n
D
1.3200 … 1.5300, sapphire prism
Accuracy Refractive index n
D
±0.0002 (corresponds typically to
±0.1 % by weight)
Repeatability and stability correspond to accuracy
Speed of response 1 s undamped, damping time selectable up to 5 min
Calibration With Cargille certified refractive index liquids over full
range of n
D
1.3200 … 1.5300
COREOptics No mechanical adjustments
Digital measurement 3648 pixel CCD element
Light source LED 589 nm wavelength, sodium light
Temperature sensor Builtin Pt1000
Temperature compensation Automatic, digital compensation
Chapter 10 – Sensor specifications
133
