Vaisala PR-23 Series - Table 14 EHEDG Certified Elbow Flow Cells, Connection Sanitary Clamp 2.5 in; Table 15 Elbow Flow Cells with Prism Wash Nozzle for PR-23-AC-XX-HSS

Table 14 EHEDG certified elbow flow cells, connection sanitary clamp 2.5 in
Model Description
AFC Elbow flow cell
Sensor connection
‑H Sanitary clamp, 2.5 in
Material of construction
SS AISI 316 L
Process connection
‑H Sanitary clamp
Pipe section diameter
20 50 mm (2 in)
Flow cell inlet type
‑SI Straight pipe
EHEDG
‑EH EHEDG Type EL Class I Certified Model
Table 15 Elbow flow cells with prism wash nozzle for PR‑23‑AC‑xx‑HSS
Model Description
AFC Elbow flow cell
Sensor connection
‑H Sanitary clamp, 2.5 in
Material of construction
SS AISI 316 L
Process connection
‑H Sanitary clamp
Pipe section diameter
10 25 mm (1 in)
15 40 mm (1.5 in)
20 50 mm (2 in)
25 65 mm (2.5 in)
1)
30 80 mm (3 in)
1)
Chapter 10 – Sensor specifications
103
