11.3.2 Safe‑Drive isolation valve SDI2‑23
14
Item
Pcs.
Part No.
Descrip�on
1
1
PR-11000 SDI flange and nozzle
6
1
M12 nut A4
weld assembly SAF 2205
7
1
SDI isola�on valve handle
*
1
PR-11001 DN 40 ball valve assembly: parts 2, 6, 7
8
1
Safety lock screw
2
1
DN 40 ball valve
9
1
Safety lock
*
1
PR-11009 SDI body assembly: parts 3, 8, 9, 10
10
1
Spring 1.5x14x20 Lesjöfors no. 2371
3
1
SDI body
11
1
PR-11002
SDI box packing set
4
1
PR-11023 SDI steam wash nozzle SN
12
1
PR-11003
O-ring 50x5 EPDM
4
1
PR-11024 SDI high pressure wash nozzle WP
13
4
PR-11008
DIN 912 M10 x 110 screw + nut
5
1
PR-11025 Nozzle isola�on valve assembly for SDI2
14
1
PR-11026
Locking bracket for isola�on valve
Figure 94 Safe‑Drive isolation valve parts
