12. Take a firm hold on the handwheel and the handle and pull out r
etractor with sensor
inside.
A firm hold of the t
ool is essential as the combination of the tool and
the sensor is noticeably heavier than retractor alone.
WARNING!
To ensure isolation valve after the Safe‑Driv
e tool with the sensor has been removed,
you can bolt a standard ANSI 1.5 in 105 lbs blind flange to Isolation valve with ½ in
(M12) bolts and nuts. A lock can be added to Isolation valve handle.
The sensor tip is hot and may be covered with liquor. It is
r
ecommended to rinse the sensor tip and isolation valve with hot water.
WARNING!
PR-23 Series User Guide
IM-EN-PR23-E
