Vaisala PR-23 Series - Interconnecting cable; Interconnecting cable model code; Interconnecting cable specifications

Feature Specification
Current outputs Two current outputs c
onfigurable independently to
indicate process concentration or temperature of
either sensor.
Sensor connectivity, DTR One or two sensors can be connected to the
tr
ansmitter. Sensors independent of each other: own
parameter sets and usable in dierent applications.
Sensor connectivity, STR Only one sensor can be connected to the transmitter.
Used with the In
trinsically safe sensor
PR‑23‑…‑IA/‑IF/‑CI.
Transmitter protection class Enclosure IP66, Nema 4X
Pollution degree Pollution degree 2
Installation Indoor
Indicating transmitter weight 4.5 kg (10 lbs)
Altitude Max. altitude 2000 m
Ambient temperature 0 … 45 °C (32 … 113 °F)
Displa
y operating temperature 0 … 50 °C
(32 … 122 °F), display storage temperature
‑20 … 60 °C (‑4 … 140 °F).
Relative humidity 0 … 100 %
Wet location Not applicable
