Valtra Versu N174 V

5. Disconnect the hoses and electric connectors from the windscreen washer
fluid reservoir.
1
2
GUID-A69A54E0-CCC5-4277-B746-800278F5F22D
1. Windscreen washer fluid hose
2. Windscreen washer electric connector
6. Remove the battery casing.
7. Tighten the front loader frame bolts on the right hand side.
1
GUID-297BE29C-4232-4A22-9AB2-20C1525F514E
1. Front loader frame bolt
The tightening torque is 600 Nm.
4. Maintenance
- 379 -
