8. Fit the battery casing.
9. Connect the hoses and electric connectors to the windscreen washer fluid
reservoir.
10. Attach the main electric centre to the battery casing.
Tighten the 4 fastening screws.
11. Attach the engine electric centre to the battery casing.
12. Close the battery casing.
13. Remove the latch of the air intake pipe.
GUID-C8F333DB-6F82-4DA2-836F-BDFF0F52B23B
1. Latch
2. Fastening screw
3. Air intake pipe support
Unscrew the fastening screw and remove the latch.
4. Maintenance
- 380 -
